MMAC-6800无风扇嵌入式工控机

结构参数
箱体结构	全铝型结构
表面处理	整机黑白双色阳极氧化
安装方式	附双安装脚条协助固定
前面板端口	1HDMI 1MIC-in & 1Lin-out 4DB9 RS232 for COM1-COM4 4USB3.0 1SW远程开机
指示和控制	POWER带灯感应开关、4G/PWR/WIFI/HDD/LAN1/LAN2/LAN3/LAN4工作指示灯
电源输入	9~36V浪涌隔离宽压DC供电
总体尺寸	269243116mm 长宽高
系统参数
处理器	Skylake平台，支持六代、七代、奔腾、酷睿、i3、i5、i7系列处理器
芯片组	Skylake平台
内存	2*DDR4L SO-DIMM 2133/2400MHz，UP to 32GB
磁盘	提供三个磁盘位置，2*SATA接口，PCIE-M.2插口
显示	1DVI-I、1HDMI、1*VGA
网口	6*lntel I211 10/100/1000M RJ45端口
音频	Realtek ALC662音频控制器
USB	后面板4USB 2.0、前面板4USB3.0
串口	4RS-232端口、2RS-232/422/485可选端口、采用浪涌，隔离，静电保护
扩展槽	2PCI 1PCIeX4
看门狗	0~255秒可设置
系统参数
工作温度	-20℃~70℃
相对温度	0~90%@40℃（无凝结）
振动	50~500Hz，1.5G，0.15mm峰值
冲击	15G（11ms）
