GEA-8501

主要特点：

GEA-8501单板计算机

- CPU/GPU RK3188 A9 4核 1.6GHZ
- 内存/1G
- 存储/（1）板载EMMC 4G （2）SDx1
- 3G/ WCDMA/CDMA2000/GPRS/SMS 双网无需双待天线外置支持3G共享
- WIFI /802.11b/g/n (802.11a possible).

产品型录

产品介绍
产品规格
档案下载

GEA-8501单板计算机

GEA-8501
硬件规格
操作系统	Android 4.2.2
CPU/GPU	RK3188 A9 4核 1.6GHZ
内存	1G
存储	（1）板载EMMC 4G （2）SDx1
3G	WCDMA/CDMA2000/GPRS/SMS 双网无需双待天线外置
3G	支持3G共享
WIFI	802.11b/g/n (802.11a possible).
WIFI热点	提供API,WIFI热点，可到8个连接
RJ45网络	1个10/100 LAN
麦克风	标准音频口
扬声器	Audio Realtek ALC5631V晶片. 1W双声道
显示	（1）1个HMDI大口需要支持19201080 1360768，1366768三种分辨率，出厂默认设置为1366768 （2）1个LVDS 24BIT双通道（3）1VGA PIN排针
GPIO	IO接口5个，有输入、输出、中断输入能力
硬件看门狗	硬件看门狗
USB	4个USB 2.0，HOST 或Client每个提供标准500ma电流，1个OTG模式
串口	6个 3线DB9串口,其中2个DB9包含RS232/422/485三种协议；4个RS232
支持外接鼠标	可以外接鼠标，以便触屏损坏的时候操控PC Box
电源	DC 12V , 4-PIN DIN with LOCK,
外观尺寸	18cm * 15cm * 5cm
海岸线	WIFI/3G天线，2USB,电源接头，4COM/2个RS232/2COM(RS232/422/485),1个10/100LAN
其他
工作温度	0～55摄氏度
设计寿命	5～7年
